Check out our plant
Sujan Chemoplast Pvt. Ltd. have an aim of providing and fulfilling all distillation requirements, company owns plant with following facility.
| Reactor No | Reactor Capacity | Stirrer | Packed column Height | Total Height | Column packing | Column Diameter | Condenser | Product cooler |
|---|---|---|---|---|---|---|---|---|
| R1 | 7000 ltrs | Anchor | 12 mtr | 14 Mtr | Melapack 500 | 600 mm | 45 M. Sq | 15 m. Sq |
| R2 | 7000 ltrs | Anchor | 12 mtr | 14 Mtr | Melapack 500 | 400 mm | 45 M. Sq | 15 m. Sq |
| R3 | 7000 ltrs | Turbine | 6 mtr | 8 Mtr | Wire Guage | 600 mm | 45 M. Sq | - |
| R4 | 7000 ltrs | Turbine | Reaction Vessel |
Material of construction
All reactors, columns, column packing, receivers, feed tanks, condensers, product coolers, piping and fittings are made from SS 316. There are other minor variables such as compatibility of material of construction with existing plant installations, plant operating conditions, ease of maintenance, and cleaning requirements.
We have a full-fledged operations unit across all distillation requirements. Our
plant’s regular upgrading, maintenance and safety measures assure
efficient
productivity in the lowest turn-around-time.
VACCUM
WE HAVE A WATER EJECTOR FOR PILOT PLANTS IN LABORATORY SO THAT WE CAN CARRY OUT DISTILLATION BATCHES UNDER VACUUM.
- WE HAVE HANDS ON DISTILLATION OF FOLLOWING PRODUCTS UNDER VACUUM:
- DIMETHYLFORMAMIDE, N METHYL PYRROLIDONE, MONO ETHYLENE GLYCOL, MIXED GLYCOLS, BROMOBENZENE, 3,3,5 TRIMETHYL CYCLOHEXANONE, 1 BROMO 3 CHLOROPROPANE, DIMETHYL ACETAMIDE
- FOR SAFE RELEASE OF VACUUM, WE USE NITROGEN PURGING
- PRODUCTS HAVING HIGH BOILING POINT AND/OR HIGH SPECIFIC GRAVITY ARE CHARGED THROUGH VACUUM IN TO THE VESSEL
We have a full-fledged operations unit across all distillation requirements. Our
plant’s regular upgrading, maintenance and safety measures assure
efficient
productivity in the lowest turn-around-time.
HEATING
For sufficient heating we are having one 10 lakh kilo calorie thermax make thermopack, which enables us to get temperature up 260°C.
We have a full-fledged operations unit across all distillation requirements. Our
plant’s regular upgrading, maintenance and safety measures assure
efficient
productivity in the lowest turn-around-time.
Cooling
We are having a 300 tr paharpur cooling tower which provide delta T of 5°C. Condensers are designed in such a way that it provides maximum cooling effect and causes least evaporation loss.
We have a full-fledged operations unit across all distillation requirements. Our
plant’s regular upgrading, maintenance and safety measures assure
efficient
productivity in the lowest turn-around-time.
Fractionation
Precisely designed columns with sufficient diameter and height combined with sulzer packings provides high no. Of theoretical plates and least pressure drop, giving us high degree of fractionation, which enables good separation between mixture of two or more than two solvents.
We have a full-fledged operations unit across all distillation requirements. Our
plant’s regular upgrading, maintenance and safety measures assure
efficient
productivity in the lowest turn-around-time.
Storage
We have 2 vertical MS storage tanks of 15000 ltr each for storing crude / spent raw materials and 4 vertical ss storage tank of 20000 ltr for storing finished materials for distillation equipped with deep pipes and vent breather valves. Also we have under roof storage facility for storing distilled material drums .
We have a full-fledged operations unit across all distillation requirements. Our
plant’s regular upgrading, maintenance and safety measures assure
efficient
productivity in the lowest turn-around-time.
